Features
Simplicity
Plug-and-Play with no software required
Easy installation of PoE devices where a power outlet is not available
Reduces installation and network equipment costs
Provides power over existing network cabling to PoE devices such as access points, IP cameras and IP phones
Lightweight and compact
802.3af compliant with output PoE power of 0.4 A at 48 V
Gigabit Connectivity
Power Over Ethernet (PoE) Injector for 10/100/1000T connections delivers power up to 100 metres (328ft)
Connect your devices at Gigabit speeds, all within a compact device
Technical Specifications
Ports
P + Data Port (out)
IEEE 802.3af compliant
Supports half/full-duplex operation
IEEE 802.3 compliant
IEEE 802.3u compliant
IEEE 802.3ab compliant
10/100/1000BASE-T port
Data Port (in)
Supports half/full-duplex operation:IEEE 802.3 compliant,IEEE 802.3u compliant,IEEE 802.3ab compliant,10/100/1000BASE-T port
Physical:Dimensions (L x W x H):109.8 x 62.2 x 24.5 mm
Weight:65 grams
Power:Consumption: 19.2 watts max
Output: 0.4 A at 48 V
Temperature:Operating: 0 to 50 °C (32 to 122 °F);Storage: -20 to 70 °C (-4 to 158 °F)
Humidity:Operating: 10% to 90% non-condensing;Storage: 5% to 90% non-condensing
Certifications: CE,FCC, VCCI, C-Tick, IC
